TECHNICAL SPECIFICATIONS
Power Requirements (Voltage may vary outside U.S) AC power line 115 volt, 15 amp circuit
Size (L x W x H) 104 x 34 x 68” (264 x 86 x 173 cm)
Unit Weight 589 lbs (267 kg)
Step-up Height 8.6” (22 cm)
Maximum User Weight 400 lbs (181 kg)
ENTERTAINMENT
Interactive Courses
Streaming Entertainment Apps (Discover SE3 only)
Goal Workouts: Time, Distance, Calories, Heart Rate, Starter Interval, Flat, Hill, Rolling Hills, Random, Climb
Fitness Test Protocol: Life Fitness Fit Test
CONNECTIVITY
Networking Capabilities: CSAFE-Ready
Internet: Via CAT6 or CAT5e (Shielded Recommended)
Wireless Connectivity: IEEE 802.11a/b/g/n (Standard for Discover SE3 Only)
Bluetooth® Connectivity
NFC Connectivity (Discover SE3 only)
RFID Connectivity (*optional)
SERVICE
LFconnect Asset Management
Open Platform with App Developer Website
Flash Programmable via USB Stick
PRODUCT FEATURES
Heart Rate Monitoring : Polar® Telemetry and Bluetooth® Heartrate (optional chest strap required), Lifepulse™ Digital Heart Rate Monitoring with DSP (Digital signal processing)
Console Options: Discover SE3, Discover SI, Explore (*optional)
Attachable TV System (For Discover SI and Explore) (*optional)
Stride Length Interval Variable Stride Length 0 – 36” (0 – 91.4 cm)
Oversized Non-Slip Pedals
26 Resistance Levels 0-25 At-Your-Fingertips Resistance Controls (Located on the moving arms)
Two Wheels for Easy Mobility
Frame Color Options: Arctic Silver, Black Onyx, Diamond White, Titanium Storm (*optional)
Headphone Jack 3.5 mm stereo
WARRANTY
2-year limited warranty on all mechanical and electrical components
1-year labor
Attachable TV System for Discover SI and Explore: 2-years electrical and mechanical parts; 90 days labor
